Przełącznik zarządzalny XGS2220-54-EU0101 F L3, 24x1G RJ45 2x10mG

• IEEE 802.3z 1000BASE-X
• IEEE 802.3ab 1000BASE-T Ethernet
• IEEE 802.3an 10G BASE-T Ethernet
• IEEE 802.3ae 10 Gbit/s Ethernet over fiber
• IEEE 802.3af PoE
• IEEE 802.3at PoE plus
• IEEE 802.3bt (60 W) PoE over 4 pair
• IEEE 802.3az EEE
• IEEE 802.3x flow control
• IEEE 802.1AB LLDP/LLDP-MED
• IEEE 802.1Q VLAN tagging
• IEEE 802.1p Class of Service (CoS) prioritization
• IEEE 802.1X port authentication

• No. of hardware queues per port (Standalone/stacking): 8/6
• Storm control and event log: Broadcast, multicast, unknown unicast (DLF)
• Port-based rate limiting (ingress/egress)
• Rate limiting per IP/TCP/UDP per port
• Policy-based rate limiting
• 802.3x flow control
• 802.1p Class of Service (SPQ, WFQ, WRR, hybrid-SPQ combination capable)
• DiffServ (DSCP)
• Storm Control: Broadcast/Unknown
• Multicast/Unknown Unicast (DLF)

• SNMP v1, v2c, v3
• SNMP trap group
• RMON (1, 2, 3, 9)
• ICMP echo/echo reply
• Syslog
• IEEE 802.1AB LLDP*/LLDP-MED
• Custom default
• Syslog (IPv4/IPv6)
• Display port utilization
• Support NebulaFlex Pro for Cloud Management

• L2 multicast
• IGMP snooping (v1, v2, v3)
• IGMP snooping fast leave
• IGMP snooping immediate leave
• Configurable IGMP snooping timer and priority
• IGMP snooping statistics
• IGMP throttling
• IGMP filtering
• IGMP proxy mode & snooping mode selection
• Multicast load balance over trunking port
• Static mulitcast
• MVR support
• MLD snooping (MLD v1/v2)

• Max. 1 K IPv4 entries
• Max. 512 IPv6 entries

• Kabel zasilający
• Zestaw do montażu w stojaku

100 - 240 V AC, 50/60 Hz

441 x 270 x 44 mm
